The variability of formats and sizes in basins is very wide, although the standards of a single bowl are usually about 60cm wide and 45cm deep. Minimum sizes and height where the basin should be installed These options turn out to be ideal in small bathrooms and projects in which the number of sought-after elements to be installed is reduced to the max.
The latest bathroom designs bank on joining toilets and bidets to become a single element, such as smart toilets and sanitary spray hand showers. The installation height of the wall-hung toilets will be 45cm from the ground. One way to further optimise the space is offered by the use of toilets with wall-concealed cisterns, inside the partition, or the models of compact and wall-hung toilets, which are smaller than the standard ones.
If they are next to a wall, the minimum free space should be 20cm, and if there is an element on their side, they should not be placed less than 15cm away for greater usability. The toilet and bidets must have a minimum space of 70cm in width and 120cm in length. Incorrect distances between sanitary elements lead to uncomfortable bathrooms When the individual trap system is used, the drainage branches of the sanitary equipment must be connected to a bypass pipe which flows into the drain, or if this is not possible, then into the toilet hose, with a registrable head with a screw tap.The joints of the drains to the drainpipes must have the greatest possible inclination, not less than 45º.No facing drains must be placed or supported on a common pipe.
Basins, bidets and bathtubs must have an overflow. The drain toilet drain to the drainpipes will be carried out directly or through a 1m maximum connection hose. The gradient should not exceed 10% in either bathtubs or showers. The elements with an individual trap, namely: basins and bidets must have a maximum 4m distance to the drainpipe, with gradients between 2.5 and 5%. The distance of the drain trap to the drainpipe must not be greater than 2m and the branches that are connected to the drain trap must have a maximum length of 2.5m, with a gradient between 2-4%. If this is not possible because of the design, its connection to the toilet hose is allowed. Connect the equipment to the drainpipes. The layout of the network must be simple and optimum so that the water flow is by gravity. Comply with the regulations on the evacuation of toilets by CTE (technical building code), whose objective is to optimise the water evacuation network and the use of energy resources:. Some questions that need to be answered are the following: Will we have built-in elements such as toilet cisterns? Do our bathroom sizes make us opt for compact models? What will the bathroom be like? With one or two bowls? Floor standing, countertop or recessed? Will a shower or bathtub be installed? Will we count on a bidet? Count on the bathroom equipment we need beforehand, since it is mostly static, and it involves an installation prior to its placement. Plan the special needs of the space and the people who will make use of it. The minimum size for a small bathroom with en suite shower or bathtub, toilet and basin, and as long as a sliding door is included, will be 150cm x 150cm for an en suite bathtub bathroom and 135cm x 150cm for an en suite rectangular shower bathroom.īut before drawing the plan for our bathroom, following these steps is recommended. This space can be reduced if we opt for compact or embedded elements, as well as sliding doors. The minimum size of a bathroom which includes a toilet and a basin is 140cm x 95cm in a rectangular floor plan, and 120cm x 120cm in a square floor plan, with a hinged door. Therefore, in all bathroom planning, there are minimum sizes that must be respected so that our project is a usable space. The function in the bathroom should prevail over the shape. Layout plan for a rectangular 4 m2 bathroom. Layout plan for a small 1.5 m2 bathroom.
Where to put plug sockets in your bathroom. Bath and shower tap installation height. Minimum dimensions for bathroom cabinets and mirror installation height. Minimum washbasin dimensions and installation height. In this article, we'll take a look at how to best use your available space to get the perfect bathroom layout: This is why how you lay out your bathroom is so important: when you get it right, functionality and interior design work together in perfect harmony. Regardless of the size of your room, making the most of the space you do have is key to achieving maximum comfort and practicality.
